SDC 1581S - Page 8

P:\INST INSTRUCTIONS\DELAYED EGRESS\INST-1581S REV F2 12-22 Page 8
RED
BLK
GRN
BLU
BRN
WHT
ORG
YEL
RED
BLK
GRN
BLU
BRN
WHT
ORG
YEL
POWER -
POWER +
COM
NO
NC
COM
NO
NC
+
-
1581S Mini Delayed Egress
Magnet
(Set DIP switch to Auxiliary)
PSB560 Request-To-Exit
Touch Sense Bar
(Remote Trigger Option)
1581S Mini Delayed Egress
Magnet
(Set DIP switch to MASTER)
PSB560 Request-To-Exit
Touch Sense Bar
(Remote Trigger Option)
RED
BLK
WHT
BLU
RESET
BYPASS
OR
ACCESS
600 Series
Power Supply
728RU or 728RUL3
Key Switch
Reset Station
COM
NO
NC
WHT
ORG
YEL
RED
BLK
GRN LED (+)
LED (+)
LED (-)
L3
OPTION
1581S-TC3 Tandem Cable
System Wiring – Pair of Doors
3 or 5
conductors
8 conductors
Power
Supply
To Fire Panel – Dry, Closed Contact
AC Mains
2 conductors
8 conductors
8 conductors
4 conductors
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
WARNING:
APPLICATION OF VOLTAGE TO THE DRY CONTACT INPUTS OF THIS UNIT
WILL CAUSE PERMANENT DAMAGE AND VOID THE WARRANTY
Smoke Detection System
Dry, Closed Contact
S
To Smoke Detection System – Dry, Closed Contact
Patient Monitoring System
To Patient Monitoring System – Dry, Open Contact
