SDC 1581S - Page 7

P:\INST INSTRUCTIONS\DELAYED EGRESS\INST-1581S REV F2 12-22 Page 7
RED
BLK
GRN
BLU
BRN
WHT
ORG
YEL
RED
BLK
GRN
BLU
BRN
WHT
ORG
YEL
POWER -
POWER +
COM
NO
NC
COM
NO
NC
600 Series
Power Supply
1581S Mini Delayed Egress
Locking Magnet
PSB560 Request-To-Exit
Touch Sense Bar
(Remote Trigger Option)
RED
BLK
WHT
BLU
RESET
BYPASS
OR
ACCESS
728RU or 728RUL3
Key Switch
Reset Station
RED
BLK
GRN LED (+)
LED (+)
LED (-)
L3
OPTION
System Wiring – Single Door
+
(-)
8 conductors
3 or 5 conductors
8 conductors
Power
Supply
To Fire Panel – Dry, Closed Contact
AC Mains
2 conductors
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
WARNING:
APPLICATION OF VOLTAGE TO THE DRY CONTACT INPUTS OF THIS UNIT
WILL CAUSE PERMANENT DAMAGE AND VOID THE WARRANTY
To Smoke Detection System – Dry, Closed Contact
S
Smoke Detection System
Dry, Closed Contact
Patient Monitoring System
To Patient Monitoring System – Dry, Open Contact
Connection to a Infant/Patient Monitoring,
Optional Equipment and Smoke Detection
System has not been investigated by UL.
