11. Cable sizes
Laying mode = cables on cable tray or racks not perforated / admissible voltage drop = 5% / Multiconductors.
Cable type PVC 70°C (example H07RNF) / Ambient temperature =30°C.
Cable lengths
0 to 50m 51 to 100m 101 to 150m
mm² / AWG mm² / AWG mm² / AWG
Rated Current (A)
Single-phase Three-phase Single-phase Three-phase Single-phase Three-phase
10 4 / 10 1.5 / 14 10 / 7 2.5 / 12 10 / 7 4 / 10
16 6 / 9 2.5 / 12 10 / 7 4 / 10 16 / 5 6 / 9
20 10 / 7 2.5 / 12 16 / 5 4 / 10 25 / 3 6 / 9
25 10 / 7 4 / 10 16 / 5 6 / 9 25 / 3 10 / 7
32 10 / 7 25 / 3 35 / 2
40 16 / 5 35 / 2 50 / 0
50 16 / 5 35 / 2 50 / 0
63 25 / 3
50 / 0
70 / 2 / 0
12. EC Declaration of conformity
Name and address of manufacturer
SDMO, 12 bis rue de la Villeneuve, CS 92848, 29228 BREST CEDEX 2
Description of the equipment
Product Generating set
Make SDMO
Type NEO 2000
Rated output: 1480 W
G. G. Le Gall, the manufacturer's authorised representative, hereby declares that the product conforms to the following EU Directives:
98/37/EC / Machinery Directive.
73/23/EEC / Low Voltage Directive (modified by Directive 93/68/EEC).
89/336/EEC / Directive on Electromagnetic Compatibility (modified by directives 92/3/EEC and 93/68/EEC).
2000/14/EC / Directive relating to the Noise Emission of Outdoor Equipment.
For Directive 14 /2000 /EC
- Notified Body:
CETIM SERVICE DIFFUSION
BP 67 F60304 - SENLIS
- Compliance procedure: Appendix VI
- Sound power level guaranteed (Lwa): 95 dB(A).
References to harmonized standards used
o EN12601/EN1679-1/EN 60204-1
11/2008
G. Le Gall
