SDMO VERSO S User Manual

4
L1 (A)
L2 (B)L3 (C)
ABC
L1 (A)
L3 (C)L2 (B)
ACB
ABC
ACB
ABC/ACB
Conguration, Conguration, Conguración, Konguration, Conguratie, Конфигурация
OPTION
Allen size 4
Hexagonal Metric
5,0 Nm / 44,1 lb-in
Slotted head 3,5 mm
0,45 Nm / 3,97 lb-in
Slotted head 3 mm
0,5 Nm / 3,97 lb-in
Allen size 4
Hexagonal Metric
5,0 Nm / 44,1 lb-in
!
31616121301NE 125A
31616121201NE 125A
31616126201NE
63A
35A
80A
100A
125A
160A
25
16
35
35
50
50
50
35
mini maxi
50
50
70
70
mm
2
10 to 70 mm²
# 8 to # 00 AWG
6 to 50 mm²
# 10 to # 0 AWG
15 mm / 0,59"
10 to 70 mm²
# 8 to # 00 AWG
6 to 50 mm²
# 10 to # 0 AWG
15 mm / 0,59"
0,5 to 1,5 mm²
# 20 to # 14 AWG
0,5 to 1,0 mm²
# 20 to # 16 AWG
6 mm / 0,236"
0,5 to 2,5 mm²
# 20 to # 14 AWG
0,5 to 1,5 mm²
# 20 to # 16 AWG
6 mm / 0,236"
Raccordement, Connection, Conexión,
Anschluss, Aansluiting, Подключение
x8
