Sea Eagle Boats Inc. 19 N. Columbia Street, Ste1, Port Jefferson, NY 11777 • 1-800-748-8066 • Staff@SeaEagle.com
EZLite™ Kayaks| SETUP: VALVES & PUMPS
Remove Valve Cap
EZLite10 has a floor
chamber and top chamber,
with one valve each. Twist
cap counterclockwise and
pull it out of valve body.
Using Recessed Valve
Press the stem button down
and turn it ¼ turn in either
direction so it pops UP when
released. When the stem is
up, the valve is closed for
inflation and will hold air.
To let air escape for
deflation, press button and
turn stem ¼ turn and release
it. It should stay in the down-
ward position.
Locate an area large enough
to unfold the EZLite™
avoiding hazards that could
damage the kayak or injure
you.
Inflate the floor and top
chambers. Working pressure
is 5-10 psi. Do not exceed
10 psi.
EZLite™ Kayaks| ASSEMBLY & INFLATION
Attach a Hose
To inflate the boat, attach
the hose with hook-in
adapter to pump handle by
twisting the collar into the
threaded opening until hose
is tight (about 1/8 turn).
Double Action Hand Pump
Hand pump inflates on up
and down strokes when in
the double action mode. In
single action mode the
handle comes up easily. The
down stroke is assisted by
body weight.
Note: If your pump is
different than this one, check
the instructions page of our
website for instructions, or
call us for help.
Check the hose end that
goes in the board’s valve. It
should have hooks to lock it
in the valve opening.
Tip: Always have the manual pump available, even if
you primarily use an electric pump.
Switch Modes
Begin inflating in the double
action mode for a faster fill.
Air flows into chamber on
the up and down strokes.
The modes are indicated on
the collar in raised lettering.
Use the lever to switch
between modes.
When handle becomes too
difficult to lift in double
action mode, rotate lever
counterclockwise to single
action.
To Next Page
