Position the mount over
the pre-drilled holes
designated for it and
bolt the mount to the
floorboard using the bolts
and wing nuts.
Locking tongue should
point to side of boat.
Now slide base of the
swivel seat (or base of
the pedestal) into the
mounts. Make sure that
the spring loaded lever
mechanism locks into
place (up position).
Bolt the pedestal directly
to the bottom of the swivel
seat. Four 1/2” screws and
wingnuts are provided.
Pedestal (OPTIONAL)
The pedestal is included
in several FoldCat boat
packages and includes
four 1/2” bolts and four
wingnuts. The 375FC can
be fitted with up to two
pedestals.
Note: Make sure that
all hardware is secured
tightly before every use.
Scotty Rod Holder
Holds a bait caster reel in
a cushioned cradle. Slot in
the front allows for a
spinning reel to be
securely held in place.
Includes side/deck
mount. A Phillips Head
screwdriver (not included)
is needed.
Scotty Rod Holder consists
of a surface mount base,
adjustable rod holder
and four #6 x 1” phil truss
stainless steel screws. A #2
phillips head screwdriver is
needed (not included).
Orient the base so the
“Inboard” arrow is
pointing toward the center
of the boat. Secure base
to the crossboard with the
screws. This is a one-time
installation.
Oars & Oarlocks
Each oarlock includes one
oarlock pin, two bolts,
two knurled knobs and
two washers. First, attach
the oarlock to the middle
floorboard.
ASSEMBLY & INFLATION
