The MB-50 needs no extra nozzles to
inflate the main air chambers of your
SE330 & SE370. Just insert the pump
into the valve and switch it on. Use the
plastic extender tube and the large
nozzle to inflate the seats. Do not drop
your pump or move it suddenly while it
is on.
Self Bailing Drain Valves
The SE330 & SE370 have one drain
valve at the stern. It should be left
closed for dry paddling on open water
or opened for ocean surf or mild
whitewater (up to class 3).
Deluxe Inflatable Seat
Equipped with two one-way valves, this seat should be
inflated so it is rigid and reasonably hard. You should be able
to push your finger about 1/2” into a well inflated deluxe seat,
which will make it firm enough for good back support. If
overinflated the seat will bulge out in the center of both
pillows and will not be comfortable to sit on. Please also note
that you can change the center of gravity by the hardness or
lack of hardness in the bottom seat compartment - i.e. a
softer bottom compartment lowers your seating position.
For use in the SE330 &
SE370, attach the straps
to the D-rings on the
seat (as shown in the
picture to the left) and
place the seat in the
boat. The tubes of the
SE330 & SE370 will hold
the seat in place.
.
SEC Seat
This seat is equipped with
small pipe valves, and should
be inflated with the small
nozzle. (See Valves for
details).
For use in the SE330 &
SE370, place the seat in the
boat. The tubes of the SE330
& SE370 will hold the seat in
place.
Paddles
Our AB-30 7' 10” (4 Part)
Double End Asymmetric
Paddles feature anodized
aluminum shafts with
Fibrylon blades. It has a 65
degree feather capability. It
is durable and lightweight
(enough to float on water).
The blades of all our paddles can be either parallel or
feathered, in which case one blade is positioned 90 degrees
to the other. This can be a big help when paddling into a stiff
breeze because the blade not in the water will slice through
the wind with little resistance.
Feathering the blades complicates the motion of the stroke,
so it’s not recommended for new kayakers right away.
There are 6 parts to each AB30 Paddles:
2 straight middle sections, 2 blade sections & 2 drip guards.
To assemble, first join the 2
straight sections with the 3
holes (used for feathering)
in the center and slide a drip
guard over each open end
of the shaft.
Next, attach a blade section
to each end and complete
your AB30 Paddle.
SE330 & SE370 Inflation Monitor
The SE330 & SE370 feature
an inflation monitor diagram
to help you gauge the
correct pressure.
As you inflate your SE330 &
SE370, the hull material will
stretch so that the printed diagram will expand to match the
clear plastic strip included with your kayak.
