1
19
1/B
15
16
17
18
3
5
6
7
8
9
10
10
11
11
12
14
13
4
2
1) Meccanismo Air Control completo Complete Air Control mechanism S77310
1B) Set completo valvola Air Control Oil pneumatic dump valve set S77336
2) O-Ring 2031 O-Ring 2031 S101017
3) Maschio attacco rapido Male connection S75036
4) Base corpo plastica Air Control Air Control plastic body base S77313
5) Set tasti scarico Air Control Air Control exhaust buttons set S77315
6) Tasto carico Air Control Air Control inflate button S77316
7) Spina PRO 2000 ADV - X FIRE 15x2 PRO 2000 ADV - X FIRE 15x2 pin S311116
8) Coperchio Air Control Air Control plastic cover S77314
9) Cover Air Control Air Control metal cover S77317
10) Vite TSC+INOX M4x35 Air Control Air Control screw M4x35 stainless steel S77330
11) Vite TSC+INOX M4x25 Air Control Air Control screw M4x25 stainless steel S77331
12) Dado ES. INOX M 4 UNI 5588 Air Control M 4 UNI 5588 Air Control nut S77332
13) Dado ES. INOX M 4 cieco M 4 Air control box nut S77333
14)Guarnizione ad anello Ring gasket S75028
15) Guarnizione a disco Plate gasket S75031
16)Ghiera valvola Air Control Air Control fastening ring nut S77318
17) Molla valvola sovrappressione Overpressure spring S75034
18) Valvolina di non ritorno per flangia Air Control exhaust valve S77337
19) Molla inox salvatubetto Stainless steel spring S77327
Gruppo di comando PRO 2000 ADV - PRO 2000 ADV inflator
