Seada SD-MV-0401 - Application Example

8. Application Example
6/6
DC 1 2V
INPUT
IN 3 IN 4IN 2IN 1
HDMI VGA AUDIO
OUTPUT
Power Supply
DVD or Blu-ray Player
DVD or Blu-ray Player
2.0 Speakers
UHDTV
TV or Monitor
