SeaDoo 2001 UTOPIA 185 User Manual

LMR2002-001_00-02A.FM V
Section 03 ENGINE
Subsection 04 (MAGNETO SYSTEM)
MAGNETO SYSTEM
717 Engine
03-04-1
F01D4WS
12
11
5 Nm
(44 lbfin)
13
9 Nm
(80 lbfin)
Loctite
242
4
6
8
Loctite
242
7
6 Nm
(53 lbfin)
Loctite
242
6 Nm
(53 lbfin)
9
Loctite
242
5
6 Nm
(53 lbfin)
3
14
Loctite
242
4
Loctite
648
10
15
145 Nm
(107 lbfft)
Anti-seize
lubricant
2
9 Nm
(80 lbfin)
1
LMR2001_005_03-04A.FM
Page heading
indicates section
and subsection
detailed.
Tightening torque nearby fastener.
In this case, nut must be torqued to
145 Nm (107 lbfft).
Exploded view assists
you in identifying
parts and related
positions.
TYPICAL PAGE
F00A1WS
Illustration number
for publishing
process.
Subsection title
indicates
beginning of the
subsection.
Dotted box
contains parts of
a particular
model or an
exploded view.
Page numbering system:
03: ENGINE section
04: MAGNETO SYSTEM subsection
1: First page of this subsection
Italic sub-title
above exploded
view indicate
pertaining models.
Drop represents a
liquid product to be
applied to a surface.
In this case Loctite
242 to screw
threads.
Bold face number
indicates special
procedure
concerning this part.
CAUTION: Pay attention to torque
specifications. Some of these are in
lbfin instead of lbfft. Use appro-
priate torque wrench.
Document
number for
publishing
process.
INTRODUCTION
