SeaDoo Seascooter RS1 User Manual

PARTS DIAGRAM
1 Outer Nose Cone Protector
2 Outer Nose Cone
3 Front Foil
4 Vent Plug
5 Inner Nose Cone
6 Battery Pod Handle
7 Battery Pod
8 Side Latches
9 Base Latch
10 PCB (Printed Circuit Board)
Box Assembly
11 Rear Foil
12 Triggers
13 Handle
14 LED Battery Status Indicator
15 Master Switch
16 Front Grille
17 Nozzle Support
18 Propeller
19 Nozzle
20 Rear Grille
21 Fin x 2
(NOT included with RS3)
22 Charger
23 Extended Charging Cable
24 Rubber Ring x 2
25 Pump
26 Pump Nozzle
27 Ballast weight x 4
(NOT included with RS3)
28 Silicone Grease
28
1
3
4
5
6
22
23
24
25
26
27
7
10
8
11
9
13
12
14
15
16
1718
19
20
21
2
1
5
