Seagate Video 2.5 Product Manual, Rev. H 24
Configuring and Mounting
Figure 5 Mounting Dimensions (for 1-disk models) (alternate basedeck)
100.350
+
-
0.200
0.250
69.850 ± 0.250
2.499 ± 1.270
7.949 ± 1.270
(16.520)
(22.450)
(90.600)
(14.000)
2X (3.000)
7.000 0.200
2X M3 X 0.5-6H
MOUNTING HOLES: BOTH SIDES
4MM MIN. SCREW DEPTH FROM
M3 PADS. NO THRU.
3.5+.075-.3X90
(13.430)
(3.500)
BASE
BOTH SIDES
4 X M3 X 0.5-6H
2.5MM MIN FULL THREAD. NO THRU
3.5 +.075 -.3 X90
RECOMMENDED
TEMPERATURE
MEASUREMENT
LOCATION
