Seagate BarraCuda Product Manual, Rev. F 25
Configuring and Mounting
Figure 6 Mounting Dimensions (for 2-disk models)
100.35
+
-
0.20
0.25
69.850
0.250
22.450
16.520
7.949
1.270
2.499
1.270
(90.600)
(14.000)
2X (3.000) BOTH SIDES
7.000
0.200
BASE
(13.430)
(3.500)
2X M3 X 0.5-6H MOUNTING
HOLES: BOTH SIDES
4MM MIN SCREW DEPTH
FROM M3 PADS. NO THRU
3.5 +.075 -.3 X90
4 X M3 X 0.5-6H
2.5MM MIN FULL THREAD. NO THRU
3.5 +.075 -.3 X90
RECOMMENDED
TEMPERATURE
MEASUREMENT
LOCATION
