Seagate Constellation CS - Seagate Constellation CS Specifications; Standard Drive Models; Performance Metrics; Reliability and Data Integrity Features

Specifications 3 TB
1,2
2 TB
1
1 TB
1
Standard Models ST3000NC002 ST2000NC001 ST1000NC001
Seagate Instant Secure Erase Options ST3000NC000 ST2000NC000 ST1000NC000
Interface SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s
Performance
Spindle Speed (RPM) 7,200 7,200 7,200
Cache, Multi-segmented (MB) 64 64 64
SATA Transfer Rates Supported (Gb/s) 6.0/3.0/1.5 6.0/3.0/1.5 6.0/3.0/1.5
Sustained Data Transfer Rate (MB/s) 600 600 600
Seek Average Read/Write (ms) 9.5/10.5 9.5/10.5 9.5/10.5
Max Sustained Data Rate, OD Read (MB/s) 150 to 180 150 to 180 150 to 180
Rotational Vibration Tolerance @ 20Hz to 1500Hz, w/RVFF (rad/s
2
) 12.5 12.5 12.5
Linear Random Vibration @ 10Hz to 500Hz (G
rms
ref) 4.9 4.9 4.9
Configuration
Heads/Discs 6/3 4/2 2/1
Bytes per Sector (512-byte emulation) 4,096 4,096 4,096
Reliability/Data Integrity
Load/Unload Cycles (25°C, 50% relative humidity) 300,000 300,000 300,000
Non-recoverable Read Errors per Bits Read, Max 1 per 10
14
1 per 10
14
1 per 10
14
Mean Time Between Failures (MTBF) 800,000 800,000 800,000
Power-on Hours 8,760 (24×7) 8,760 (24×7) 8,760 (24×7)
Power Management
Operating Mode (typical, W) 8.0 8.0 8.0
Idling Power (W) 5.53 5.53 5.53
Standby/Sleep Mode (W) 0.77 0.77 0.77
Voltage Tolerance (including noise)
5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
5V ± 5%
12V ± 10%
Environmental
Operating Temperature (°C) 5 to 60 5 to 60 5 to 60
Non-operating Temperature (°C) −40 to 70 −40 to 70 −40 to 70
Relative Humidity, Operating/Non-operating (%) 5 to 90/5 to 95 5 to 90/5 to 95 5 to 90/5 to 95
Acoustics (typical/max bels) 2.5/2.6 2.4/2.5 2.2/2.3
Physical
Height (in/mm)
3
26.1/1.0 28 26.1/1.028 20.0/0.787
Width (mm/in)
3
101.85/4.010 101.85/4.010 101.85/4.010
Depth (mm/in)
3
147. 0 0 /5.787 147.00 /5.78 7 147.0 0 /5 .78 7
Weight (g/lb) 626/1.38 535/1.18 400/0.88
Carton Unit Quantity 20 20 25
Cartons per Pallet 40 40 40
Cartons per Layer 8 8 8
Special Features
Seagate Instant Secure Erase Optional Optional Optional
Flagged Write Uncorrectable (Logical Block Management) Yes Yes Yes
PowerChoice
™
On-Demand Power Savings Yes Yes Yes
SeaTools
™
Diagnostic Software Yes Yes Yes
SMART Drive Monitoring and Reporting Yes Yes Yes
Hotplug Operation (per SATA Rev. 3.0 Specications) Yes Yes Yes
Enterprise CS Phone Support Limited Limited Limited
Limited Warranty (years) 3 3 3
www.seagate.com
 AMERICAS SeagateTechnologyLLC10200SouthDeAnzaBoulevard,Cupertino,California95014,UnitedStates,+14086581000
 ASIA/PACIFIC SeagateSingaporeInternationalHeadquartersPte.Ltd.7000AngMoKioAvenue5,Singapore569877,+6564853888
EUROPE,MIDDLEEASTANDAFRICA SeagateTechnologySAS16-18rueduDôme,92100Boulogne-Billancourt,France,+33141861000
©2012SeagateTechnologyLLC.Allrightsreserved.PrintedinUSA.Seagate,SeagateTechnologyandtheWavelogoareregisteredtrademarksofSeagateTechnologyLLCintheUnitedStatesand/orother
countries.Constellation,PowerChoiceandSavvioareeithertrademarksorregisteredtrademarksofSeagateTechnologyLLCoroneofitsafliatedcompaniesintheUnitedStatesand/orothercountries.
Allothertrademarksorregisteredtrademarksarethepropertyoftheirrespectiveowners.Whenreferringtodrivecapacity,onegigabyte,orGB,equalsonebillionbytes;andoneterabyte,orTB,equalsone
trillionbytes.Yourcomputeroperatingsystemmayuseadifferentstandardofmeasurementandreportalowercapacity.Inaddition,someofthelistedcapacityisusedforformattingandotherfunctions,
andthuswillnotbeavailablefordatastorage.Actualdataratesmayvarydependingonoperatingenvironmentandotherfactors.Seagatereservestherighttochange,withoutnotice,productofferingsor
specications.DS1767.1-1210GB,October2012
1
Onegigabyte,orGB,equalsonebillionbytes;andoneterabyte,orTB,equalsonetrillionbyteswhenreferringtodrivecapacity.
2
SeagaterecommendsvalidatingyourcongurationwithyourHBA/manufacturertoensurefull3TBcapacitycapabilities.
3
ThesebasedeckdimensionsconformtotheSmallFormFactorStandard(SFF-8301)foundatwww.sffcommittee.org.Forconnector-relateddimensions,seeSFF-8323.
