Barracuda ATA IV Family Product Manual, Rev. B 29
Word Description Value
0
Configuration information:
•
Bit 15: 0 = ATA; 1 = ATAPI
•
Bit 7: removable media
•
Bit 6: removable controller
•
Bit 0: reserved
0C5A
H
1 Number of logical cylinders
16,383
2 ATA-reserved
0000
H
3 Number of logical heads
16
4 Retired
0000
H
5 Retired
0000
H
6 Number of logical sectors per
logical track: 63
003F
H
7–9 Retired
0000
H
10–19 Serial number: (20 ASCII
characters, 0000
H
= none)
ASCII
20 Retired
0000
H
21 Retired
0400
H
22 Obsolete
0000
H
23–26 Firmware revision (8 ASCII
character string, padded with
blanks to end of string)
x.xx
27–46 Drive model number: (40
ASCII characters, padded
with blanks to end of string)
ST380021A
ST360021A
ST340016A
ST320011A
47 (Bits 7–0) Maximum sectors
per interrupt on Read multi-
ple and Write multiple (16)
8010
H
48 Reserved
0000
H
49 Standard Standby timer,
IORDY supported and may
be disabled
2F00
H
50 ATA-reserved
0000
H
