SEAGATE LAPTOP THIN HDD PRODUCT MANUAL, REV. K 6
DRIVE SPECIFICATIONS
2.1.1 LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1,
where n is the number of
guaranteed sectors as defined above.
Refer to Configuring and Mounting the Drive on page 16 (words 60-61 and 100-103) for additional information about 48-bit addressing
support of drives with capacities over 137 GB.
2.2 Physical organization
Drive model Read/write heads Number of discs
ST500LT012, ST500LT015, ST500LT025 andST500LT034
2 1ST320LT012, ST320LT015, ST320LT025 andST320LT032
ST250LT012, ST250LT015, ST250LT025 andST250LT028
2.3 Recording and Interface Technology
Recording method Perpendicular
Recording density 1875 Kb/in
Track density 375 ktracks/in avg
Areal density 670 Gb/in
2
avg
Spindle speed 5400 RPM +/- 0.2%
Sustained data transfer rate 100 MB/s max
I/O data-transfer rate 600 MB/s max
2.4 Physical Characteristics
Height 6.8 +/- 0.2 mm (0.268 +/-.008 in)
Width 69.85 +/- 0.25 mm (2.750 +/- 0.010 in)
Length 100.35 +0.20 / -0.25 mm (3.951 +0.008 / -0.010 in)
Typical weight <95 g (0.209 lb)
Cache buffer 16 MB (16,192 KB)
Interface Serial ATA (SATA)
All models
