Seagate Video 3.5 HDD Product Manual, Rev. B 11
www.seagate.com
2.8 Power specifications
The drive receives DC power (+5V or +12V) through a native SATA power connector. (Refer to
Figure 3).
2.8.1 Power consumption
Power requirements for the drives are listed in
Table 2 on page 11. Typical power measurements are based on an average
of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature.
• Spinup power
Spinup power is measured from the time of power-on to the time that the drive spindle reaches operating speed.
• Read/write power and current
Read/write power is measured with the heads on track, based on a 16-sector write followed by a 32-ms delay, then a
16-sector read followed by a 32-ms delay.
• Operating power and current (CE profile)
Operating power is measured by simulating a typical PVR operating environment, using a 50% write, 50% read algo-
rithm.
• Idle mode power
Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random
track location.
•Standby mode
During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write elec-
tronics are in power-down mode.
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase
acoustic and power to operational levels. Measurement was taken in Idle 1 mode.
†5W IDLE, Standby and Sleep, with DIPLM enabled
Table 2 DC power requirements for 1TB and 500GB models
Power dissipation (1-disk values shown) Avg (watts 25°C) Avg 5V typ amps Avg 12V typ amps
Spinup —— 1.6
Idle* † 2.502 0.152 0.145
Operating 3.676 0.385 0.145
Standby 0.819 0.15 0.005
Sleep 0.819 0.15 0.005
