Seagate ST500VM000 - Page 28

Seagate Video 3.5 HDD Product Manual, Rev. B 27
www.seagate.com
60–61 Total number of user-addressable LBA sectors available
(see Section 2.2 for related information)
*Note: The maximum value allowed in this field is: 0FFFFFFFh
(268,435,455 sectors, 137 Gbytes). Drives with capacities over 137
Gbytes will have 0FFFFFFFh in this field and the actual number of
user-addressable LBAs specified in words 100-103. This is required for
drives that support the 48-bit addressing feature.
0FFFFFFFh*
62 Retired 0000
H
63 Multiword DMA active and modes supported
(see note following this table)
xx07
H
64 Advanced PIO modes supported (modes 3 and 4 supported) 0003
H
65 Minimum multiword DMA transfer cycle time per word (120 nsec) 0078
H
66 Recommended multiword DMA transfer cycle time per word
(120 nsec)
0078
H
67 Minimum PIO cycle time without IORDY flow control (240 nsec) 0078
H
68 Minimum PIO cycle time with IORDY flow control (120 nsec) 0078
H
69–74 ATA-reserved 0000
H
75 Queue depth 001F
H
76 Serial ATA capabilities xxxx
H
77 Reserved for future Serial ATA definition xxxx
H
78 Serial ATA features supported xxxx
H
79 Serial ATA features enabled xxxx
H
80 Major version number 01F0
H
81 Minor version number 0028
H
82 Command sets supported 346B
H
83 Command sets supported 7D69
H
84 Command sets support extension
(see note following this table)
4133
H
See Word 108-111 note.
(4133
H
= 1000000100101
binary)
85 Command sets enabled 34xx
H
86 Command sets enabled BE01
H
87 Command sets enable extension 4133
H
88 Ultra DMA support and current mode (see note following this table) 00A4
H
89 Security erase time 00A4
H
90 Enhanced security erase time 00A9
H
92 Master password revision code FFFE
H
93 Hardware reset value xxxx
H
95 Stream Min. Request Size 0000
H
96 Streaming Transfer Time - DMA 0000
H
97 Streaming Access Latency- DMA and PIO 0000
H
Table 7 Identify Device commands (Continued)
Word Description Value
