INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 1
90519
1
10 of 29
Section 2: ELECTRICAL INSTALLATION
2.0 INTRODUCTION
This section for electrical installation explains how to mount the electrical equipment and how to
connect the electrical cables.
Reference Documents & Drawings:
•
90510 – Seakeeper 1 Hardware Scope of Supply
•
90511 – Seakeeper 1 Cable Block Diagram
•
90512 – Seakeeper 1 Cooling Water Schematic
•
TB 90191 – Seawater Cooling Pump Recommendations
•
TB 90573 – Seakeeper 1 Display Options
o
TB 90478 – Garmin and Seakeeper Compatibility
o
TB 90479 – Raymarine and Seakeeper Compatibility
o
TB 90480 – Simrad and Seakeeper Compatibility
o
90600 – Seakeeper 1, 5” Touch Display
Figure 1: Seakeeper 1 Isometric View with Electrical Connections
