INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 1
90519
1
27 of 29
Section 5: INSTALLATION & START-UP CHECKLIST
5.0 INTRODUCTION
Reference Documents & Drawings:
• 90516 – Seakeeper 1 Bolt-In Installation Details
• 90511 – Seakeeper 1 Cable Block Diagram
• 90512 – Seakeeper 1 Cable Block Diagram
• 90437 – Seakeeper Commissioning Form
• SWI-105 Commissioning Checklist
• 90594 – Seakeeper 1 Operation Manual
• 90569 – Seakeeper ConnectBox and Application Quick Start Guide
The Installation and Start-Up Checklists in this section provide an overview of the primary step covered
in the installation manual and should be referenced throughout the installation process. Upon
completed of the Seakeeper 1 installation the installer should commission each Seakeeper unit with
the Seakeeper Commissioning Form (90437). The Commissioning Checklist Work Instruction (SWI-105)
provides a checklist of items to inspect and verify during the commissioning process and serves as a
supplement to the Seakeeper Commissioning Form (90437).
All Seakeeper stabilizers should be commissioned to verify installation specifications and
requirements have been implemented properly. The commissioning process should include
completion of the Seakeeper Commissioning Form (90437), all the items in this the Installation
Checklist, and verification of Seakeeper 1 operation without alarms or abnormal behavior.
5.1 INSTALLATION CHECKLIST
5.1.1 MECHANICAL CHECKLIST (SECTION 1)
 Seakeeper foundation installed per requirements of the Seakeeper 1 Bolt-In Installation Details
(90516).
o Structure designed to accommodate Seakeeper 1 forces, as defined in Drawing No. 90516
with a minimum safety factor of 2.0.
o Foundation is co-planar within 0.06” (1.5mm).
 Clearances around Seakeeper meet service and operating specifications and no obstructions
are within the Seakeeper envelope.
 Seakeeper 1 Bolt-In Kit is installed (P/N 90599), includes: M14-2 x 94mm Hex Head Bolt, M14
wedgelock washer, upper snubbing washer, isolation mount tube sleeve, and lower snubbing
washer at each corner.
 Foundation bolts torqued to specification: 135 ft-lbs (156 N-m).
 Seakeeper 1 cover can be removed to access and service the unit.
