Controller Configuration
This step will assign the location, orientation and zero position for each Controller.
The on-screen prompts for Controller conguration will have you start with both Actuators
unplugged from the Distribution Module. Plug in the Port Side Actuator cable to the Distribution
Module and select the Port Controller Cable Routing.
Note: Due to engineering eorts to make the Seakeeper Ride equipment more versatile for ease of
installation, the Controllers must follow a Conguration procedure that tunes them for proper
operation. This requires the rst-time installation to determine the location of the Controller, the
cable side of the Controller and the zero position of the controller. Before proceeding you will need
to know which cable end belongs to which Controller (which cable end is Port side and which cable
end is Starboard side). You will also need to know how the Actuator is mounted within the
Controller. It can be ipped 180 degrees in order for the cable to be routed as Port or Starboard to
avoid hull structure or obstacles when pulling the cable from the actuator to the Distribution
Module.
