SeaLand Vacuum Pump - PARTS LIST

9
PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
310537
310538
342812 342813
342814 342815
342816
342817 342818
341792
342820
342821
342822
342823
341797
340704
Seal and Gasket Kit
Bearing and Race Kit
Input Shaft 920 MDSN *(SPECIFY RATIO, SERIAL/MODEL NUMBERS TO ORDER)
Worm Gear 920 MDSN *(SPECIFY RATIO, SERIAL/MODEL NUMBERS TO ORDER)
Output Shaft Cover (800519)
Output Shaft *(SPECIFY RATIO, SERIAL/MODEL NUMBERS TO ORDER)
Input Shaft Cap (800261)
5/16"-18 x 7/8" Hex Head Screw-SS
5/16" Split Ring Lock Washer SS
Gear Reducer Housing 920 MDSN (790509)
5/16"-18 x 1-1/4" Hex Head Screw SS
Motor Adapter Flange (800254)
Retaining Ring (10141)
1
1
1
1
1
1
1
12
16
1
4
1
1
Item
PART NUMBER
*30:1 *20:1
Description Qty
Speed (Gear) Reducer
