Page 3 of 5
Parts Information:
Mini Lathe & Drilling Machine
Model No: SM2503
Item Part No. Description
1 SM. CHANGE GEAR COVER
2 SM. CAP SCREW M4x8
3 SM. CAP SCREW M4x12
4 SM. HINGE L*B=38*31
5 SM. WASHER 4
6 SN.S STEEL NUT M4 ZINC DIN934 (SINGLE)
7 SM. CANTILEVER
8 SM. M6 HALF NUT S/C
9 FWM.SB FLAT WASHER M6 BLACK (SINGLE)
10 SM. COMPRESSION SPRING
11 SM. SPACING RING
12 SM. COVER FOR SPINDLE BOX
-- SM. VARIABLE SPEED CONTROL
-- SM. FEED CLUTCH KNOB
13 SM. ROTATE SPINDLE
14 SM. KEY 3x6
15 SM. PROTECT COVER FOR CHUCK
16 SM. CAP SCREW M4x8
17 SM. CAP SCREW M5x8
18 SM. REAR SPLASH GUARD
19 SM. MOTOR
20 SM. KEY 3x16
21 SM. CHECK RING 8
22 SM. TIMING PULLEY
23 SM. SUPPORT PLATE
24 SM. SCREW M4x8
25 SM. WASHER 6
26 SM. SPRING WASHER 6
27 SM. SCREW M6x20
28 SM. WASHER 8
29 SM. SPRING WASHER 8
30 SM. SCREW M8x20
31 SN.S STEEL NUT M18 ZINC DIN934(SINGLE)
32 SM. SPINDLE GEAR
33 SM. SPACING RING (I)
34 SM. SPINDLE TIMING PULLEY
35 SM. SPACING RING (II)
36 SM. BEHIND OIL SEAL (RING)
37 B/ BEARING 30205
38 SM. SPINDLE BOX
39 SM. FRONT OIL SEAL (RING)
40 SM. KEY 6x36
41 SM. SPINDLE
42 SM. KEY
43 SN.S STEEL NUT M6 ZINC DIN934 (SINGLE)
44 SM. SCREW M6x25
Item Part No. Description
45 SM. CHUCK FLANGE
46 SM. ROUND CAP SCREW M4x12
47 SM. 80mm 3-JAW CHUCK
48 SM. HANDLE SCREW (SET OF 3)
49 SM. SMALL HANDLE
50 SM. HANDWHEEL
51 SN.SD STEEL NUT M6 DOMED (SINGLE)
52 SM. SPRING STEEL
53 SM. DIAL
54 SM. SCREW BASE
55 SM. KEY 2x18
56 SM. TAILSTOCK SCREW
57 SM. SCREW M5x8
58 SCB.SB SOCKET HEAD CAP SCREW M5x20 BLACK
59 SM. TAILSTOCK CASTING
60 SM. WEDGE
61 SM. LOCK HANDLE
62 SM. TAILSTOCK QUILL
63 SM. DIAL
64 SM. SCREW M5x14
65 SM. SCREW BRACKET
66 SM. BED LEAD RAIL
67 SM. LEADSCREW
68 SB. STEEL BALL 6.4mm
69 SM. COMPRESSION SPRING
70 SM. SCREW M6x10
71 SM. PIN 3x14
72 SM. CLUTCH BRACKET
73 SM. CLUTCH
74 SM. KEY 3x22
75 SM. SHAFT
76 SM. KEY 3x14
77 SM. GEAR SHAFT BRACKET
78 SN.S STEEL NUT M5 ZINC DIN934 (SINGLE)
79 SM. SUPPORT PLATE
80 SM. WASHER
81 SM. CHANGE GEAR Z=72
82 SM. CHANGE GEAR Z=19
83 SM. CHANGE GEAR Z=76
84 SM. CHANGE GEAR Z=24
85 SM. GEAR SLEEVE
86 SM. GEAR SHAFT
87 SM. SCREW M5x8
88 SM. SPACING RING
89 SM. CHANGE GEAR Z=90
90 SM. SCREW M5x25
