INSTRUCTIONS FOR

SUPERMIG

WELDER

SUPERMIG180.V3

MODEL No:

Original Language Version

© Jack Sealey Limited

SUPERMIG180.V3 Issue No:5(D) - 11/11/16

Table of Contents

Questions and Answers:

H
holtericAug 18, 2025
Why does my Sealey SUPERMIG180.V3 Welding System produce porous welds?
- E
  erinhowardAug 19, 2025
  If you're experiencing porous welds with your Sealey Welding System, several factors could be at play. Ensure your gas cylinder is open and the gas flow is correctly regulated. Check for and clean a clogged gas cup, and shield the welding site from drafts that might blow away the shielding gas. Also, make sure the joints are free from rust and dirt. The torch should be held at the correct angle and distance (8 to 10mm) from the workpiece. Inspect hoses, connections, and the torch assembly for any gas leaks, and ensure the gas cup is correctly positioned. Finally, the electrovalve might be faulty and need cleaning or replacement.
D
Dustin RodriguezAug 20, 2025
Why does my Sealey Welding System power source stop?
- R
  Richard HodgeAug 21, 2025
  If your Sealey Welding System stops unexpectedly, it's likely due to the overheating protection being activated because of an overload. The protection will automatically reset once the transformer has cooled down, which usually takes about 15 minutes.
B
barbara58Aug 23, 2025
What to do if there is no weld current in Sealey SUPERMIG180.V3 Welding System?
- A
  Allison GregoryAug 23, 2025
  If you're not getting any weld current from your Sealey Welding System, there could be several reasons. A rectifier might have blown and need replacement. There could be a bad connection between the clamp and the workpiece; in this case, you should clean or grind the contact surface and weld area. Alternatively, there might be a break in the earth lead, which would require repair or replacement, or a break in the torch lead, also requiring repair or replacement.
M
Monica AllenAug 26, 2025
Why does wire feed unevenly in Sealey Welding System?
- K
  katiejenningsAug 26, 2025
  If the wire on your Sealey Welding System feeds unevenly, it could be due to several reasons. The liner might be dirty, so try cleaning it from the machine forward using compressed air. The gas cup or tip could be defective and need replacement. The gas cup might also be spattered, requiring cleaning or replacement. A feed roller groove could be clogged, requiring cleaning, or deformed, requiring replacement. Lastly, the pressure roller tension might be improper and need adjustment.
W
William WallerAug 28, 2025
What to do if wire does not feed in Sealey Welding System?
- A
  alextannerAug 28, 2025
  If the wire on your Sealey Welding System isn't feeding but the feed roller is rotating, first check if the pressure roller is improperly adjusted and adjust the tension accordingly. Also, the torch liner might be clogged with dirt, copper, or dust; clean it from the machine forward using compressed air, and replace the liner if it's too dirty. Additionally, the gas cup or tip could be defective and need replacement. Finally, the wire might be deformed, so check and adjust the roller tension if necessary.
C
Christopher DixonAug 30, 2025
How to fix unstable arc on Sealey Welding System?
- L
  Lisa GloverAug 30, 2025
  If you're getting an unstable arc with your Sealey Welding System, it might be due to incorrect settings, so check them. Another cause might be impurities in the weld area, so try cleaning or grinding the workpiece. Also, a worn or defective gas cup could be the culprit, so consider replacing it.
A
Alan FrazierSep 1, 2025
What causes excessive penetration in Sealey SUPERMIG180.V3?
- A
  Adam MathisSep 1, 2025
  If you're experiencing excessive penetration with your Sealey Welding System, it's likely due to the weld current being too high, so decrease the power and wire speed. Another reason could be that the weld speed is too slow, so move the torch faster. Finally, the torch distance might be incorrect; it should be 8-10mm from the workpiece.
J
Joshua MillerSep 3, 2025
Why is the weld bead too wide with my Sealey SUPERMIG180.V3 Welding System?
- G
  Gregory HurleySep 3, 2025
  If you're getting a weld bead that's too wide with your Sealey Welding System, it could be because the weld current is too high, so decrease the power and wire speed. Another possibility is that the weld speed is too low, so move the torch faster and weave less. Lastly, the arc might be too long, so bring the torch closer to the workpiece.
J
Jennifer LaneSep 6, 2025
How to improve penetration on Sealey SUPERMIG180.V3 Welding System?
- J
  jdawsonSep 6, 2025
  If you're experiencing poor penetration with your Sealey Welding System, it might be because the weld current is too low, so increase the power and wire speed. Another reason could be that the arc is too long, so bring the torch closer to the workpiece.
L
lawrenceortizSep 8, 2025
Why is electrode sticking in gas cup of Sealey SUPERMIG180.V3 Welding System?
- A
  Anthony HancockSep 8, 2025
  If the electrode is sticking in the gas cup of your Sealey Welding System, it could be due to a worn or defective gas cup, which would need replacement. Another cause might be a deformed electrode, so check the roller tension. Also, the wire speed might be too slow; see the recommendations for wire speed.

Sealey SUPERMIG180.V3 Specifications

General

Welding Process	MIG/MAG
Input Voltage	230V
Input Frequency	50/60Hz
Rated Input Current	16A
Welding Current	30-180A
Max Output Current	180A
Wire Diameter Range	0.6-1.0mm
Wire Feed Speed	2-16m/min
Cooling System	Fan cooled
Protection Class	IP21S
Duty Cycle	60% @ 180A
Wire Capacity	5kg
Gas Type	CO2, Argon, Mixed Gas

Summary

Welder Safety Guidelines

Electrical Safety Precautions

Electrical safety precautions, RCD use, and cable checks.

General Operating Safety

General operating safety, PPE, and work area conditions.

Gas Cylinder Safety

Safe handling and storage of gas cylinders.

Introduction and Product Specifications

Product Introduction and User Guidance

Overview of Supermig models and initial user guidance.

SUPERMIG180.V3 Technical Specifications

Technical details and performance data of the SUPERMIG180.V3.

Assembly and Preparation Procedures

Gas Platform and Wheel Assembly

Steps for assembling the gas platform and attaching wheels/castors.

Gas Cylinder and Regulator Installation

Guide for mounting the gas cylinder and connecting the regulator.

Assembly and Preparation Steps

Torch Cable Connection

Procedure for connecting the torch cable to the welder.

Wire Reel Fitting (5kg & 15kg)

Instructions for installing both 5kg and 15kg welding wire reels.

Feeding Welding Wire Through Torch

Steps to feed welding wire from the spool through the torch.

Assembly and Preparation Steps

Wire Feed and Tension Adjustment

Adjusting wire tension, clutch, and drive roller settings.

MIG/MAG Welding Process and Setup

Understanding the MIG/MAG process and initial welding preparation.

MIG/MAG Welding Operation Guide

Setting Welder Controls and Parameters

Guidance on setting power output, wire speed, and voltage.

Welding Materials and Spot Welding Techniques

Advice for welding steel/aluminium and performing spot welding.

Overload Protection and Ratings Plate Information

Understanding overload protection and the welder's ratings plate.

Welder Maintenance and Care

Wire Feed Unit and Torch Maintenance

Cleaning and maintaining the wire feed unit and torch assembly.

Replacing Consumables: Tip, Roller, Liner

Steps for replacing contact tips, drive rollers, and torch liners.

Gas Cup Maintenance and Cleaning

Cleaning and maintaining the gas cup.

Troubleshooting Common Issues

Common Welding Problems and Solutions

Detailed guide to identifying and resolving common welding issues.

Environmental and Regulatory Compliance

Environmental Protection and WEEE Regulations

Guidelines for recycling and disposing of the product responsibly.
