3. OPERATION
4. MAINTENANCE
3.1 Measuring
3.1.1 With the vehicle ignition OFF, remove the fuse from the circuit to be tested and insert it into the fuse
jack (fig.1.2), this ensures the correct level of circuit protection.
3.1.2 Insert the plug into the vehicle fuse socket.
3.1.3 Switch on the vehicle ignition if required, to energise the circuit and then switch on the tester fig.1.5.
3.1.4 Operate the circuit under test and the LCD will display the measured current.
p WARNING! The Fuse blade may become hot during testing. Allow to cool before touching.
4.1 Battery Replacement
Power is supplied by a 12V A23S battery. The ‘BAT’ symbol appears on the LCD display when
replacement is required.
p WARNING! To avoid electric shock ensure all inputs are disconnected from any circuit before
removing the battery cover.
To replace the battery, remove the screw from the back of the unit and remove the cover.
Remove the exhausted battery and replace with a new observing the connection polarity.
Replace cover.
NOTE! Dispose of old battery according to local authority guidelines.
4.2 Cleaning
Clean using a soft damp cloth.
Store in a safe, dry, childproof location. .
01284 757500
01284 703534
Sole UK Distributor
Sealey Group,
Bury St. Edmunds, Suffolk.
www.sealey.co.uk
Web
sales@sealey.co.uk
email
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and
component parts without prior notice. IMPORTANT: No liability is accepted for incorrect use of product. WARRANTY: Guarantee
is 12 months from purchase date, proof of which will be required for any claim. INFORMATION: For a copy of our latest
catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
TA120, TA121 Issue No: 1 - 11/11/08
1
2
3
4
5
TA120
