VS8700 - 1 - 110108
20
1) Use SCROLL button to select I/M Readiness from Diagnostic
Menu and press ENTER/EXIT.
If more than one module is detected, you will be prompted
to select a module before test.
Use the SCROLL button to select a module, and press
ENTER/EXIT button.
2) Wait a few seconds while the code reader validates the PID MAP.
3) If the vehicle supports both types of tests, then both types shows
on the screen for selection.
……….……I/M Readiness……………….
Reading PID…
- Please Wait -
............Diagnostic Menu...........
4/6
1) Read Codes
2) Erase Codes
3) View Freeze Frame
► 4) I/M Readiness
…………..Control Module……………..
1/3
► Engine
Module $A4
Exit
To Next Page
