4.3 Viewing Freeze Frame Data
1) To view freeze frame, use SCROLL button to select View
Freeze Frame from Diagnostic Menu and press ENTER/EXIT
button.
 If more than one module is detected, you will be prompted
to select a module before test.
 Use SCROLL button to select a module and press
ENTER/EXIT button.
2) Wait a few seconds while the code reader validates the PID MAP.
3) If the retrieved information covers more than one screen, use
SCROLL button, as necessary, until all data have been shown up.
……………View Freeze Frame……...
Reading PID.01
- Please Wait -
............Diagnostic Menu..........
3/6
1) Read Codes
2) Erase Codes
►3) View Freeze Frame
4) I/M Readiness
…………….Control Module…………….
1/3
► Engine
Module $A4
Exit
