TWIN PETROL FUEL SYSTEM.
OPEN VALVE (1) CLOSED VALVE (0)
1 – PETROL FUEL TANK
2 – FUEL TANK SENDER UNIT
3 – FUEL TANK VENT
4 – FUEL TANK FILLER
5 – FUEL FILTERS
6 – FUEL SHUT OFF VALVES
(LOCATED IN COCKPIT)
7 – FLEXIBLE FUEL FEEDER HOSES
8 – CENTRAL HEATING UNIT (OPTIONAL)
9 – CENTRAL HEATING FUEL PUMP & PRE-FILTER
10 – DIESEL TANK FOR CENTRAL HEATING UNIT
11 – FUEL CROSS CONNECTION VALVE
12 – FUEL TANK INSPECTION COVER (OPTIONAL)
13 – ANTI-SYPHON VALVE
14 – PORT ENGINE
15 – STARBOARD ENGINE
DRAWING No:20614/4/F
