Sealine International Ltd. (V1.1)
Page 52 of 61
WIRING DIAGRAMS: KEYPAGE.
BE = BLUE BK = BLACK BN = BROWN GN = GREEN GY = GREY O = ORANGE PE = PURPLE PK = PINK R = RED W = WHITE Y = YELLOW
1 = CROSS SECTIONAL AREA OF CONDUCTOR IN mm
2
- R/Y = RED WITH YELLOW TRACER
1 - AC PANEL 36 - FLOAT SWITCH 71 - POWER PANEL
2 - AFT CABIN 37 - FRIDGE 72 - PUMP
3 - AUTOPILOT 38 - FRIDGE (COCKPIT) 73 - PUMP (SHOWER)
4 - AUXILIARY 39 - FRIDGE (GALLEY) 74 - PUMP (WASTE)
5 - BATTERY (MASTER SWITCH) 40 - FRIDGE (SALOON) 75 - PUMP (WATER)
6 - BATTERY (PORT BANK) 41 - FUSE 76 - RADAR
7 - BATTERY (PORT SWITCH) 42 - GALLEY 77 - RADIO
8 - BATTERY (PORT) 43 - GENERATOR 78 - RELAY
9 - BATTERY (STARBOARD BANK) 44 - HEATING UNIT 79 - RELAY BOX
10 - BATTERY (STARBOARD SWITCH) 45 - HOB 80 - SHAVER SOCKET
11 - BATTERY (STARBOARD) 46 - INVERTOR 81 - SHORE SOCKET
12 - BATTERY BOX 47 - LAZARETTE 82 - SHOWER BOX
13 - BATTERY CHARGER 48 - LIGHT (PORT - RED) 83 - SOLENOID (LINK)
14 - BATTERY ISOLATION (PORT) 49 - LIGHT (RIDE) 84 - SOLENOID (REVERSING)
15 - BATTERY ISOLATION (STARBOARD) 50 - LIGHT (SEARCH) 85 - SOLENOID (WASHER)
16 - BATTERY SWITCH COMPARTMENT 51 - LIGHT (STARBOARD - GREEN) 86 - SOLENOID (WINCH)
17 - BILGE PUMP 52 - LIGHT (STEAMING - WHITE) 87 - SPARE
18 - BILGE PUMP (AFT) 53 - LIGHT (STERN - WHITE) 88 - STARTER MOTOR (PORT)
19 - BILGE PUMP (ENGINE ROOM) 54 - LIGHTS (AFT CABIN) 89 - STARTER MOTOR (STARBOARD)
20 - BILGE PUMP (FUSES) 55 - LIGHTS (AFT READING) 90 - SWITCH (FRONT)
21 - BILGE PUMP (FWD) 56 - LIGHTS (COCKPIT) 91 - SWITCH (HELM)
22 - BILGE PUMP WARNING LIGHT 57 - LIGHTS (DECK) 92 - SWITCH (LINK)
23 - BOW THRUSTER 58 - LIGHTS (ENGINE ROOM) 93 - SWITCHES (DOOR ENTRY)
24 - CABIN (AFT) 59 - LIGHTS (FORWARD CABIN) 94 - CIRCUIT BREAKER
25 - CABIN (FWD) 60 - LIGHTS (GALLEY) 95 - VHF
26 - CABIN (FWD) 61 - LIGHTS (PORT MID-CABIN) 96 - WASTE TANK (BLACK)
27 - CALORIFIER 62 - LIGHTS (PORT READING) 97 - WASTE TANK (GREY)
28 - COMPRESSER 63 - LIGHTS (SALOON) 98 - WATER TANK
29 - CONTROL PANEL 64 - LIGHTS (SHOWER/TOILET) 99 - WINCH
30 - DC PANEL 65 - LIGHTS (STARBOARD MID-CABIN) 100 - WINCH MOTOR
31 - EARTH 66 - LIGHTS (STARBOARD READING) 101 - WINDLASS
32 - ENGINE ROOM BLOWERS 67 - LIGHTS (STRIP) 102 - WINDLASS FOOT SWITCHES
33 - FAN 68 - LIGHTS (WINCH & DOCKING) 103 - WINDSCREEN WIPERS
34 - FAN (GALLEY) 69 - MACERATOR 104 - WIPER MOTOR PORT
35 - FAN (TOILET) 70 - MICROWAVE 105 - WIPER MOTOR STARBOARD
