SealMaster CRACK PRO 60 - Machine Picture 3 - Engine and Tank

38
CRACK PRO® GRAVITY FLOW AND DIRECT FIRE MELTER
APPLIES TO ALL DIESEL FUEL BURNER & LP GAS BURNER
PICTURE-3
17 OIL
EXPANSION TANK
18 THERMOCOUPLE
26 AGITATOR
DRIVE MOTOR
16 MATERIAL
THERMOMETER
22 FENDER
39 MATERIAL
TANK LID
32 TAILLIGHTS
15 OIL
THERMOMETER
56 HYD. TANK
20 JAW COUPLERS & 61 INSERT
60 ACCESS COVER
19 HYD. PUMP
30 MATERIAL
DISCHARGE VALVE
21 ENGINE
59 PUMP MOUNT
BRACKET
