11 Rev. 3.0 13/06/16
The control unit is supplied by the manufacturer with Safety as-
cent function disabled, to enable this function, so that after 12
hours of inactivity of the Wind Sensor, the control unit automat-
ically proceeds to perform the Safety ascent, proceed as fol-
lows: check that the extended menu 2 is enabled (WIND
SPEED LEDs and SUN/RAIN INPUT LEDs start flashing simul-
taneously), use the SEL button to navigate to the ALL MOT.
CODE LED when flashing and press the SET button: the ALL
MOT. CODE LED remains lit in a constant manner and pro-
gramming is complete. Repeat the procedure to restore the
previous configuration.
C) CODE MOT. 1 (Movement inversion Wind Sensor):
The control unit is supplied by the manufacturer with the Wind
Safety Command = Ascent Command functioning meaning that
the sensor, when it detects wind, commands a Ascent for the
fastening. If it is desired for the sensor to command fastening
Descent when Wind is detected,, proceed as follows: check
that the extended menu 2 is enabled (WIND SPEED LEDs and
SUN/RAIN INPUT LEDS start flashing simultaneously), use the
SEL button to navigate to the CODE MOT. 1 LED when flash-
ing and press the SET button: the MOT. 1 CODE LED remains
lit in a constant manner and programming is complete. Repeat
the procedure to restore the previous configuration.
D) CODE MOT. 2 (Movement inversion Wind Sensor):
The control unit is supplied by the manufacturer with the Rain
Command = Descent Command association meaning that the
sensor, when it detects rain, commands a Descent for the fas-
tening. If it is desired for the sensor to command fastening As-
cent when rain is detected, proceed as follows: check that the
extended menu 2 is enabled (WIND SPEED LEDs and
SUN/RAIN INPUT LEDS start flashing simultaneously), use the
SEL button to navigate to the CODE MOT. 1 LED when flash-
ing and press the SET button: the MOT. 2 CODE LED remains
lit in a constant manner and programming is complete. Repeat
the procedure to restore the previous configuration.
E) CODE SENS. (Movement inversion Rain Sensor):
The control unit is supplied by the manufacturer with the Rain
Command = Descent Command association meaning that the
sensor, when it detects rain, commands a Descent for the fas-
tening. If it is desired for the sensor to command fastening
Ascent when rain is detected, proceed as follows: check that
the extended menu 2 is enabled (WIND SPEED LEDs and
SUN/RAIN INPUT LEDs start flashing simultaneously), use the
SEL button to navigate to the SENS. CODE LED when flashing
and press the SET button: the SENS. CODE LED remains lit in
a constant manner and programming is complete. Repeat the
procedure to restore the previous configuration.
R
ESET
In case it is necessary to reset the control unit default factory
configuration, press the SEL and SET keys together and hold
them for more than 2 seconds so that all indicator LEDs switch
on and off at the same time.
Attention
All operations which require the opening of the casing (cables
connection, programming, etc.) must be carried out by expert
personnel during installation. For any further operation which
requires the casing to be re-opened (re-programming, repair or
installation amendments) contact the after-sales assistance.
I
MPORTANT FOR THE INSTALLER
- The device must never be used by children or persons with
reduced physical-psychological abilities, unless supervised or
trained on the functioning and the use modalities.
- Do not allow children to play with the device and keep the ra-
dio-controls away from their reach.
- ATTENTION: keep this instruction manual and respect the
important safety prescriptions contained herein. The non com-
pliance with the prescriptions may cause damages and serious
accidents.
- Frequently examine the plant to detect any signs of damaging.
Do not use the device if a repair intervention is necessary.
the products:
LG2247 – LRS2247 – LRS2247 SET – LRH2247
comply with the specifications of the Directives RED
2014/53/EU, EMC 2014/30/EU, LVD 2014/35/EU Directives.
I
MPORTANT FOR THE INSTALLER
The control unit has been designed to allow the installer to au-
tomate devices such as sun blinds and rolling window shutters
in order to submit to regulatory prescriptions in force. The ef-
fective compliance with the obligations and achievement of the
minimal safety requirements are, however, the responsibility of
the installer.
Installation must be carried out in compliance with EN 60335-
2-97 “ Safety of household and similar electrical appliances”
part 2 “ Particular requirements for drives for rolling shutters,
awnings, blinds and similar equipment”.
In this regard, realise the plant combined with this components
control unit (motor, mechanical parts, etc.) resulting conform in
satisfying the necessary safety requisites.
-The system must be disconnected from the power supply dur-
ing maintenance near automatic blinds.
-The moving parts of the drives must be installed from at least
2.5 metres from the floor.
-The fixed controls must be installed in a visible place.
-
The control unit must be permanently connected to the pow-
er supply network and not have any type of sectioning device
of the 230 Vac electric line, it will therefore be under the care of
the installer, to provide the plant with a sectioning device. It is
necessary to install a single-phase switch with over-voltage
category III. It must be positioned so as to be protected against
accidental closures.
- For connections (power supply, motors output), use flexible
cables under insulating sheath in harmonised polychloroprene
(H05RN-F) with minimum section of the conductors equal to
0.75 mm
2
.
- The connection cables must be fixed by assembling cable
clamps supplied with the product.
- In choosing the motor to combine with the control unit, keep
to the maximum power indications contained in this manual.
For a correct functioning of the radio receiver, in case of us-
ing one or more control units, the installation at a minimum
distance of at least 3 meters one from the other is recom-
mended.
If there are two ore more control units, in order to avoid radio
interference, it is recommended using only one Wireless
type Sensor.
