SEC 611HS - Regulation With Remote Sense

III Regulation With Remote Sense
+Vo
+S
-Vo
-S
HS
DC-DC
Converter
Load
+
-
twisted pair
Figure 3
G
A
C
I
Pin

TheHSSeriesprovidesregulatedoutputsattheoutputterminals.Whenthereisalargecurrentand/orthe
outputcableisofsomelength,thevoltageattheendofthecablemaybenoticeablylowerthanatthe
terminals.Theconvertercancompensateupto0.75Vofvoltagedropthroughremotesenseterminals.To
ensureaccurateregulation,usersshouldruntwoseparatewires(twistedfromthedesiredregulationpointsto
theremotesenseterminals.Eveniftheloadcurrentislow,usersshouldstillconnect+Voto+Sand–Voto–S.
Figure 2
Page 2
A
ll dimensions are in inches
