8. Technical Specifications
Model
SLL-20 SLL-30 SLL-40 SLL-50
Voltage V As shown in the name plate
Frequency Hz Applied to 50
Optimal Press. bar 0.2 0.2
Open Flow L/min 52 60 68 75
Max Power W As shown in the name plate
Outlet dia. mm OD 19 mm
Weight kg 4.5
Standard accessories L-Joint hose (with hose band)
Model
EL-60 EL-80-15 EL-80-17 EL-100
Voltage V As shown in the name plate
Frequency Hz Applied to 50
Optimal Press. bar 0.2 0.2 0.2 0.2
Open Flow L/min 105 115 120 145
Max Power W As shown in the name plate
Outlet dia. mm OD 19 mm
Weight kg 8.5
Standard accessories L-Joint hose (with hose band)
Model
EL-120W EL-150 EL-200
Voltage V As shown in the name plate
Frequency Hz Applied to 50
Optimal Press. bar 0.25
Open Flow L/min 225 265 310
Max Power W As shown in the name plate
Outlet dia. mm OD 27 mm
Weight kg 16
Standard accessories L-Joint hose (with hose band)
