ST2 Keyless Access System - Parts Description
Door Controller - Front View Door Controller - Back View
Door Controller - Wall Supporting Plate Proximity Reader
Proximity Keyfob Locking Device Protection Diode
USB Interface Cable Power Supply
Indication Leds
Red: Power
Yellow: Programming
mode
Green: successful
operation
Controller
Keypad
Female
Clicking
supports
Back screws
USB Interface
Connector
Laptop/Notebook
