Appendix C: Service Terminal
These keyboard commands are available on all screens.
90 Analog
Displays the analog values of 10 consecutive addresses for a
single circuit.
Commands
A Display next device
(address)A Display selected device at address
0 M Reset Minimum/Maximum Values
0 P Energize both sets of terminals
1 P Energize only B terminals
2 P Energize only A terminals
92 Sensitivity
Displays the Day/Night status, the default and manual
sensitivities of all sensors on an addressable circuit. Dots are
shown for any value that is not used.
Commands
C Display next addressable circuit
93 Sensitivity List Displays the value each sensitivity setting represents.
Command Description
<Del> Clear and redisplay screen.
<Tab>
View next available screen. Unused/unavailable
screens are skipped over.
<Backspace>
View previous available screen. Unused/unavailable
screens are skipped over.
0<Tab>
View Index screen showing the numbers of all available
screens.
0-127<Tab>
View Selected Screen. If selected screen is unused/
unavailable, the next available screen is shown.
0.0<Tab> TeleVideo cursor control mode.
0.1<Tab> VT100 cursor control mode.
A Silence buzzer.
D Print the date and time.
(month).(date) D Enter the date.
(month).(date).(year) D
Enter the date and year. The year may be entered as 00
to 99 in a two-digit format, or as 1991 to 2090 in a four-
digit format.
(hours).(minutes) T Set the time.
(hours).(minutes).(seconds) T Set the time.
Screen Name Description
