English 9
P Adjusting the seat depth: 1. Press the finger plate and
hold it fast
2. Push the cushion to the desired position
3. Release the finger plate, and the seat will engage
P To adjust the height of the armrests: 1. Press and
hold the button
2. Raise or lower the armrest to the
desired height
3. Release the button to lock the armrest
P To adjust the height of the armrests: 1. Press and
hold the button
2. Lift or lower the armrest to the
desired height
3. Release the button to engage the
armrest
P To adjust the depth of the armrests: 1. Press and
hold the button
2. Push the armrest cover backwards
or forwards to engage
P To swivel the armrest: up to 24° inwards and
12° outwards
P To adjust the sitting width between the armrests:
1. Slightly loosen the lever on the armrest support
under the seat.
2. Position the armrests 3. Retighten
the lever
I Adjustment of the headrest (optional)
P Push the headrest to the desired height
(it is continuously adjustable)
P Adjust the tilt of the headrest as desired
F Depth of the seat (optional)
G Adjusting the basic armrests
(optional)
H Adjusting the 4D armrests
(optional)
Height of the footring (optional for counter under-
frame version)
P Adjusting the footring: 1. Turn the knurled screw
anticlockwise – the footring loosens
2. Move the foot-
ring to the desired position
3. Tighten the knurled
screw clockwise
A
D
C G
F
