Seeburg A3 dp - Technical Specifications

A3 dp
6 Technical specifications
12
6 Technical specifications
Speaker Components
2 x 8" Nd / 1"
Description
HiMid Sound System
Amp Power
LF: 500 W AES / 110-230 V
HF: 150 W AES / 110-230 V
Rated Current
0,6 A @ 230 V
SPL (Peak @ 1m)
132 dB
Max. Input Signal
25 dBu
DSP
HDLM FPGA Processing 32 bit floating point
AD / DA
24 bit / 96 kHz
Latency
0,8 ms (analog in to analog out)
Usable Range (-6dB)
80 Hz - 20 kHz
Tuning Frequency (excursion minimum)
90 Hz
X - Overpoint (acoustical)
depends on preset
Coverage (horizontal / vertical)
90° x 60° - rotatable
Max. Splay Angle
- - -
Connectors
Neutrik XLR in/out
Neutrik PowerCon in/out
Handles
1 x
Rigging (flying points)
4 x M10 / 2x M6
35 mm pole mount
Weight
13,5 kg
Size (height x width x depth)
59,0 x 25,0 x 25,0 cm
Order No.
00240/II/dp
The technical data sheet and further information about possible applications for the system and
available accessories can be downloaded at the following Internet address:
https://www.seeburg.net/download_getfile.php?file=downloads/06-Datenblaetter/A-Serie/A3-
dp_Datenblatt_dt.pdf
