Sega Saturn sound box User Manual

ST-193-091394
Sega Enterprises, Ltd.
(RDJ, 9/27/94)
14
How to Set the SCSI ID
Follow the steps below when changing the SCSI ID. You do not need to
follow these steps if using ID=6 setting.
1. Remove the Sound Box cover.
• Make sure the power of all peripheral devices connected to the Sound
Box is off.
• Remove the Sound Box cover. There are five screws. See Figure 3.4.
BODY COVER
Figure 3.4 Removing the Sound Box Cover
2. Set the SCSI ID.
•Set the ID switch on the sound board according to Figure 3.4 and
Table 3.1.
3. Install the Sound Box cover.
• Cover the casing with the main cover and secure with five screws. See
Figure 3.4. Refer to "Remove the Sound Box cover."
