Counter Installation Manual
[continued]
6. Once the wires are untwisted you will need to cut the
yellow wire in the top left hole [harness clip facing up].
7. Now take the black wire lead from the Counter and
twist the two cut yellow wires and black lead wire
together. Solder the connection to make sure the wires
are connected completely.
8. Wrap the wire with electrical tape to cover the
exposed wires.
9.
Test the counter by putting $5 and $1 bills into the DBA.
Cut the yellow wire about 3” from the harness.
Solder the twisted wires to ensure a proper connection.
Lock box Installation Manual
For your own safety, please read through this instruction
manual that we have prepared for you thoroughly and
take precautions when using the product.
Note before assembling
1. You may need to pull the frame out of the main unit
[A] to install the Lock box over the DBA.
Tools required for assembling
• Pencil for marking
Drill/Screwdriver
Parts Included
• Lock box with Staple Hasp Mounting Screws
SuperBooth
DBA Lock box Setup Manual
