Antenna Extension Kit
Antenna Extension Kit is for antenna installation on a wall or roof, improving satellite signal.
Center column×1Extension cable 10m x1 Expansion tube×4 Self-tapping screw×4Installation base×1
CAUTION:
Whenever the location of the antenna is changed, the existing map cannot be used anymore, please create a
new map for your lawn.
WARNING:
Roof top antennas of any sort should have lightning protection and thunder protection. Proper reinforcements
are needed in case of strong winds or storms.
Overview
How to install
Connect the extension cable with the charging station. In case the cable is still not long enough, connect another 10m (33 ) extension
cable. The total length of the extension cable can be 30m (98 ). Insert the power plug into a suitable power outlet.
Affix the center column on the installation base. Install the GNSS antenna.
1
2
3
