15 [en] User Manual
Technical Data
Properties Values
Printer port
logical:
physical:
100BaseTX Fast Ethernet (IEEE 802.3)
RJ-45
Network connection
logical:
physical:
100BaseFX Fast Ethernet (IEEE 802.3)
SC (type: MMF; 50/125 µm, 62,5/125 µm)
Current input 290 mA at 5 V
Operating environment Ambient temperature: 5–40 °C
Relative humidity: 20–80 %
Dimensions Width: 52 mm
Height: 31 mm
Depth: 59 mm
Weight: 133 g
1 32 4
5
4
6
5
1. Activity LED (orange)
2. Network connector (SC, female)
3. Link LED (green)
4. Printer connector (RJ-45, male)
5. Hole with thread
6. USB port (type: Mini-B)
