Seiko 6T63A - Page 6

Cal. 6T63A
PARTS LIST
6/19
*1
*1
*2
*2
15
SWITCH SPRING SCREW
0016121
17
SECOND COUNTING
WHEEL FRICTION
SPRING
0353018
18
CHRONOGRAPH
BRIDGE
0190007
16
SWITCH SPRING
4250***
19
CHRONOGRAPH
COUPLING LEVER
0581007
25
TRAIN WHEEL
STOP LEVER
0894002
26
HAMMER OPERATING
LEVER A
0587004
20
HAMMER OPERATING
LEVER B
0587006
HAMMER
0585013**
15
SWITCH SPRING SCREW
0016121
21
SECOND
COUNTING
WHEEL
0888***
22
POSITIONING
ARBOR
0685002
23
MINUTE
COUNTING
WHEEL
0740***
24
For parts , please refer to the page 10 and 11.
For parts and , please refer to the page 10.
For parts , , , , and , please refer to the page 12 and 13.
22
16
25 26
24
2019 21
