Selden TYPE RB Mk 4 - Line Routing

6
Alternative clew outhaul arrangement.
Fig. 7:1
Fig. 7:2
Layout 1
Figs.6:suggestedarrangement.
Line routing
Reengandunreengisaccomplishedwithanendlessreenglineandanouthauloperatedeitherfromthecockpit
oratthemast.Inthelattercasetheouthaulisalsotakentotheboomormastnearthegooseneck.(SeeFig.7.1).
Endless reefing line
Ifin-mastfurlingmastistobeoperatedfromthecockpitanendlessreengline(loop)incombinationwithaself-
tailingwinchisrecommended.Reenglineshouldbeø10mmpolyesterrope.Theendlessloopmusthaveextra
lengthtoallowittobeeasilyremovedfromthewinch.Thetail-endoftheloopmustalsobebelayedonastopper.
Onmostinstallations,thereenglineneedstobefedthroughblocksandstoppersbeforemakinganendlesssplice
accordingtoSeldéninstruction595-673.Iftheblocksandstoppersarepossibletodismantle,asplicedendlessline
canbeusedaccordingtosparepartslistatpage15.
Outhaul line
Aself-tailingwinchandastopperisalsorecommendedfortheouthaulline.
FreeRatchet

Lead Blocks
Lead Blocks
Turning Blocks
Kicking Strap
Rope-Stoppers
Topping Lift
Endless Reeng
Line
Fig 6:2
Outhaul
