38 B5789-06KG-012C flange bolt M6×12×P1.0/white-zinc 1 132 51219-G7A2-0002 ground wire
6*10*200mm 1
39 51213-G7A1-1000 aircleaner support white-zinc/192F 1 133 B861.2-060G-000B
wave spring
Φ6/outer gear/zinc black plating
1
40 12010-E92F-0000 gasket,cylinder head thick/graphite/192/1.2mm 1 134 B5789-06KG-012B flange bolt M6×12×P1.0/black 1
41 11014-E88F-0000 dowel pin Φ12X20 2 135 B6177.1-06KG-000B flange nut M6/black 1
42 14443-E90F-1000 valve,exhaust EPA3/R420/butt welding/enlarged 1 136 51204-G2A1-0000
shock absorbing mount
M10*35*P1.5/Damping
rubberΦ33*30/with 2 nuts
1
43 14442-E90F-1000 valve,inlet EPA3/R420/enlarged 1 137 B6170-1000-000C
hexagon nut M10×P1.25/BYO 2
44 14410-E88F-0000 rod,push 5X166 2 138
51204-G5A3-A000 shock absorbing mount Φ8*Φ10/319451 2
45 14441-E88F-0000 lifter valve Φ9x46 2 139
44008-0800-000B nylon nut M8/black zinc 2
46 13010-E92F-0000 piston ring components 192 1 140 55012-G5AA-0000 nylon gasket black 2
47 13112-E88F-0000 piston pin clamp Φ1xΦ22.5 2 141
51229-G5AA-0001 handlebar dowel pin
M10*Φ13.5*53/Senci II 5KW
dedicated/lengthen
2
48 13101-E92F-0000 piston 192 1 142
51312-G5AA-1000 handlebar plastic plug 2
49 13111-E88F-0000 piston pin Φ20x62 1 143
51311-G5AA-0000 wheel hub cover black plastic 2
50 13200-E92F-0000 connecting rod 192 1 144
51310-G5AA-00RE wheel assy 9" 2
51 B5789-12LG-016C drain plug M12X16/white-zinc 2 145 B95-016G-000B plain washer
Φ16×Φ30×2.5/zinc plating black

2
52 B848-120H-0000 aluminium washer Φ12×Φ20×2 2 147 51301-G5AA-0000 axle
Φ16xΦ22*123/black on surface
2
53 11100-E92E-1000 crank case lacunal/electirc/192FB/new product 1 148 16006-G7A2-0000 clip, dowel pin Φ2*18mm/316510 2
53—1 15002-E68F-0000 rubber fixed block 1 149 B6177.1-08KG-000B flange bolt M8/black 2
54 11013-E88F-0000 metal clamp Φ6.5 1 150
51204-G5A3-A000 shock absorbing mount Φ8*Φ10/319451 2
55 15030-E68F-1000 oil alert three-wire/white zinc 1 151 B6177.1-10LG-000B flange nut M10×P1.25black 4
56 B5789-06KG-012C flange bolt M6×12×P1.0/white-zinc 1 152
51312-G5AA-0000 rack plug black/plastic 2
57 16001-E88F-1000 shaft governor arm surface treatment polishing 1 153 B5789-06KG-020B flange bolt M6×20×P1.0/black 4
58 15020-E88F-0100 oil sensor mechanical/188F 1 154 B5287-G7A2-000B fuel tank gasket Φ6xΦ22*2/black zinc 2
59 B6177.1-10LG-000B nut M10×P1.25black 1 155 51100-G8AA-01B4 frame components 1
60 B95-080G-000B washer plain Φ8×Φ17×1.0/black 2 156 B5789-06KG-012B flange bolt M6×12×P1.0/black 1
61 B13871-0814-A000 oil seal,swing bar Φ8xΦ14x5 1 157 B5789-06KG-012B flange bolt M6×12×P1.0/black 1
62 16006-E88F-0000 lock Φ1.0*8mm 1 158 B6177.1-06KG-000B flange nut M6/black 1
63 B5789-06KG-012C flange bolt M6×12×P1.0/white-zinc 1 159 51230-G5AA-00R1 engine fix block 1
64 16002-E88F-0000 speed control rod 188 1 160 54106-G7A1-000K clamp B8/EP 1
65 16003-E88F-0000 fine spring Φ0.4*Φ5.7*213mm*30.5per lap 1 161
17002-E68F-1000 fuel pipe φ4.5*φ8.5/CARB 0.42
66 16020-E88F-0000 arm,governor straight 1 162 54105-G5AA-0000 fuel tank switch
aperture/within O-shape
gasketΦ12x2
1
67 16031-E68F-000C bolt,governor arm M6*21/type T/white-zinc 1 163 54106-G7A1-000K clamp B8/EP 1
68 B6177.1-06KG-000C flange nut M6/blue-white zinc/GB6177.1 1 164
54100-G5AA-11RE fuel tank assy 1
69
16004-E92F-0000
spring,return
φ1.8×137mm×25.75per lap
/AP192FB/60Hz
1 164-1 54102-G2A1-0000 oil leveler 1
70 16303-E92F-0000 governor assy 192FB/controller holder 1 164-2 54150-G5A2-0000 fuel tank cover 1
71 13401-E92E-0000 balance shaft QT500-7/192FB/heavy 1 164-3 17017-G2A1-0000 fuel filter 1
72 B275-6202-03 bearing TM6202/P5 1 164-4 54103-G5AA-0000 fuel tank rubber mat 4
73 B5787-06KG-016C bearing M6×16×P1.0/white zinc 1 164-5 54104-G5AA-0000 fuel tank lining coat 4
74 14100-E92E-0000 cam shaft assy 192FB nitriding/improved 1 165 B5287-G7A2-000B fuel tank gasket Φ6xΦ22*2/black zinc 4
75 13300-E92E-A000 crankshaft assy
alternator shaft/1:5/192FB/40Cr/TM6207/P5
1 166 B5789-06KG-025B flange bolt M6×25×P1.0/black 4
76 11012-E92F-1000 crankshaft gasket Imports of non-asbestos/Interface/192 1 167 54106-G7A2-000K clamp B9.5/EP 1
77 11014-E68F-0000 dowel pin Φ8x14 middle case 2 168 54109-G7AA-0001 breather pipe
Φ5*Φ11+Φ6*Φ12.2X420mm 1
78 B275-6202-03 bearing TM6202/P5 1 169 54106-G7A2-100K clamp B12/EP/48031J 2
