NO. PART NUMBER DESCRIPTION SPECIFICATION QTY NO. PART NUMBER DESCRIPTION SPECIFICATION QTY
1 12020-E88F-0000 flange bolt assy,abnormity
M6X60/Buna-N rubber/bolt,cylinder head cover 1 94 B97.4-105G-000B plain washer
Φ10.5×Φ20×1.5/black-zinc
painting
1
2 12500-E88F-600C cylinder head assy
blue-white zinc/breathing valve plates/EPA3/
1 95 B5789-10LG-285C flange bolt M10×285×P1.25/white zinc 1
3 12002-E88F-0000 cylinder head gasket rubber washer 1 96 31610-B140-0002 carbon brush 1
4 14201-E88F-2000 waste gas pipe
garden arc/acrylate rubber/Φ10*Φ15*/35+135 1 97 31401-A120-0012 1
5 14434-E88F-0000 nut,pivot adjusting M6 hex nut 2 98 B5787-05JG-016B flange bolt M5×16×P0.8/black 5
6 14432-E88F-0000 rocker arm M6 spherical nut 2 99 B5787-05JG-012B flange bolt M5×12×P0.8/black 2
7 14431-E88F-0000 arm,valve rocker 182/188/190 2 100 31700-G9AA-0100 voltage regulator 1
8 14433-E88F-0000 bolt pivot M6*M8*56 2 101 31301-G6A1-00B4 alternator end cover 1
9 14447-E88F-0000 rotator,valve 188 2 102 B5787-05JG-012B flange bolt M5×12×P0.8/black 2
9--1 14445-E88F-0000 retainer,inlet valve spring 188 1 103 15100-E90F-1000 ignition coil assy
retainer,exhaust valve spring 188 2 104 15011-0188-0000 Spark plug cap 1
11 14751-E88F-0000 spring valve Φ3.0*Φ26*39mm*6.75per lap 2 105 B5789-06KG-025B flange bolt M6×25×P1.0/black 2
12 14448-E88F-0000
retainer,exhaust valve spring 188 2 106 15300-E92E-0000 flywheel assy 25°/electric 1
13 14444-E88F-B000 oil seal,air inlet fluororubber 2 107 15004-E88F-1200 cooling fan white/PP 1
14 14449-E88F-0000 plate,push rod guide 188 1 108 15003-E88F-0000 starting cup 1
15 B5789-10LJ-080C flange bolt M10×80×P1.25/white zinc 4 109 B6177.1-16MG-001C flange nut M16×1.5/white zinc 1
16 15010-E88F-1000 spark plug F7RTC 1 110 15600-E92F-35RE recoil starter assy 1
17 12005-E68F-000C stud bolt,exhaust M8X35stud/white zinc 2 111 B5789-06KG-012C flange bolt M6×12×P1.0/white zinc 5
18 18010-E88F-0001 muffler washer
cylinder head place,small/graphite 2 112
12014-E92F-0000
cylinderhead wind scooper
nylon/192FB/187*182*113 1
19 B6170-08KG-000C hex nut M8/white zinc/ 2 113
12014-E92F-1000 wind scooper nylon/192FB/187*52*83
1
20 B895-085G-000C spring washer Φ8.5/white zinc 2 120 34100-E88E-0000 starter relay 1
21
18020-E88F-0018 connecting pipe,muffler length:88.4 1 115 15001-E88F-0000 tension disc 1
22 53100-G8AA-05B3 muffler assy
exhaust pipeφ32/match alternatorφ190x158 1 116 15200-E88F-0000 charge coil
AC20
1
23 53217-G5B8-00B4 muffler stay matte black 1 117 B5789-06KG-031C flange bolt
M6×30×P1.0/white
1
24 B5787-06KG-016C flange bolt M6×16×P1.0/white zinc 2 118 34100-E88E-0000 Relay cap 1
25 B5789-06KG-012C flange bolt M6×16×P1.0/white zinc 2 119 34101-E88F-0000 connecting wire 1
26 18040-E88F-0000 roll over valve washer graphite/roll over valve washer 1 120
34000-E88E-2000
alternator assy
188FD/white zinc
1
27 18050-E68F-0000 roll over valve E68 1 121 B5789-06KG-031C tension disc M6×30×P1.0/white 1
28 B5789-06KG-120C flange bolt
M6×16×P1.0/white
zinc/use for roll over valve
1 122 B5789-06KG-012C flange bolt M6×12×P1.0/white zinc 1
29 11016-E88F-0000 wind board cylinder head place/188 1 123
51202-G5AA-02B4 battery holder 1
30 12200-E92F-2000 cylinder head assy 42.2CC 1 124 B5789-06KG-012B flange bolt M6×12×P1.0/black 1
31 12004-E88F-001C stud bolt,intake 188F/M6*M8*106/white-zinc 2 125
51270-14AH-2000 battery 1
32 17005-E88F-1000 gasket,air inlet
Imports of non-asbestos/Interface/188F
1 126 B6177.1-08KG-000B flange nut M8/black 2
33 17001-E88F-0100 carburator connecting block plastic/E88F 1 127 51330-G5B8-00B4 bracket assy plastic 2
34 17003-E88F-0100 carburator washer 188/interface/imports of non-asbestos 1 128 51304-G5AA-0000 bracket rubber mat black/Φ38*Φ44.5 2
35 17200-E92F-4000 carburator assy
P27-3/AP192FB/hand shank/common
nozzle/22mm/yellow hand shank
1 129 B5789-08LG-095B flange bolt M8×95×P1.25/black 2
36 17004-E88F-1000 air clearner gasket 188/interface/imports of non-asbestos 1 130
51306-G5AA-0000
handlebar rubber cover
Φ27*Φ35*220/black 1
37 14200-E90F-3000 air clearner assy
unit/CARB/selenodont
/all metal/594pa±10％/95m³/h
1 131 51320-G8AA-02B4 handlebar component Φ28*1.2 1
To Next Page
