Prescribed use
The rotary trimmer is designed for the creative cutting of paper, lm and other soft materials It is
possible to cut up to 5 sheets (80g/m
2
) at the same time.
Safety instructions
In case of any damages which are caused due to the failure to observe these
operating instructions, improper operation or the failure to observe the safety
instructions, the guarantee will expire.
● Do not carry the product at the cutting head.
● Do not overload the Paper Trimmer. Do not insert more sheets or stronger sheets than stated in
the Technical data.
● Do not touch the knife blades. Danger of injury!
● Please keep this operating manual for further reference!
● If you pass the device on to third parties, forward this operating manual as well.
Product description
The Paper Trimmer is equipped with the following features:
● transparent ruler with scale
● 3 dierent knifes for straight cut, wave-shaped cut and perforation of the paper
● cutting is possible in both directions
● additional scale on the base plate for straight and easy alignment of the material to be cut
The Paper Trimmer is equipped with the following features:
Do not touch the edge of knife blades. Danger of injury!
● Turn the cap at the cutting head towards „OPEN“ and remove it.
● Remove the knife.
● Take the desired knife out of its support at the bottom of the base plate and carefully remove the
blade protection.
● Insert the new knife into the cutting head. The axis of the knife must be inserted properly into the
receptacle of the cutting head.
● Place the cap back onto the cutting head and turn it towards „LOCK“ until it locks into place.
● Insert the replaced knife into the blade protection and place it into the support on the bottom of
the base plate.
Operation
Do not cut hard materials such as metal strips, glass etc.
Always operate the device with both hands. Use the device on a stable, at and
even surface only. Before each cut, check the knife in the cutting head for secure
fastening.
● Place the Paper Trimmer onto a non-slipping surface.
● Push the cutting head on one side of the ruler.
● Place the material to be cut with the cutting edge under the cutting ruler and bring it into the
desired position.
● Press the cutting ruler onto the material to be cut in order to x it and hold it with the other hand.
● Now, pull the cutting head in a constant movement and with slight pressure along the cutting
ruler.
Technical data
Cutting length max. 310 mm
Cutting type
Straight
Wave-shaped cut
Perforating cut
Cutting capacity max. 5 sheets (80g/m
2
)
Dimensions 382 × 55 × 120 mm
Weight 0.25kg
Warranty
A 24 month warranty is oered to the trimmer. The warranty excludes wearing components.
Visit www.sencor.eu for details on other Sencor products.
Manufacturer: Fast ČR, a.s., Černokostelecká 1621, CZ 251 01 Říčany
2020, 11/2020
