Fireplace stove SENKO SP 14
Picture 6
Kamin priključiti na dimnjak upotrebljavajući rozetu promjera 160 mm. U
slučaju da je kamin nužno oljeno smanjivati zadane promjere cijevi !
If the replace stove is far from the chimney opening, it is connected
with an additional extension pipe and elbow. The extension ue pipe must
have an adequate rise and must not be longer than 125 cm. The
connection between the chimney and the ue pipe must be completely
sealed!
4.4. FRESH AIR OPENINGS
In the room where the replace stove is installed, there must be sucient
air ow for combustion. The space must be ventilated regularly.
The opening for fresh air must be located at the bottom of the room and air
must be allowed to enter the room through it. Minimum opening dimension
must be 6 cm
2
per kW of nominal power (eg. for 30 kW  180 cm
2

opening 10×18 cm).
A pipe with a diameter of 80 mm can also
be installed on the back side of the replace
stove in the prepared opening for
entry of fresh air from the outside (picture 6).
4.5. INSTALLATION CHECK
Before the rst re, it is necessary to check whether the ue pipe is well
sealed.
