17
Specifications
Transducer principle pre-polarised
condenser microphone
Frequency response 20–20,000 Hz
Pick-up pattern cardioid
Phantom powering 48 V/2.2 mA
Sensitivity
(free field, no load at 1 kHz) 7 mV/Pa;
2.3 mV/Pa / 0.7 mV/Pa
(with pre-attenuation)
Equivalent noise level
A-weighted (DIN IEC 651) 19 dB
CCIR-weighted (CCIR 468-3) 30 dB
Pre-attenuation 0, -10, -20 dB
Bass filter linear
roll-off 130 Hz, 6 dB/oct.
cut-off 85 Hz, 18 dB/oct.
Max. sound pressure level 137/147/157 dB SPL
at 1 kHz
(depending on
pre-attenuation)
Nominal impedance 100 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions Ø 24 mm,
length: 157 mm
Weight 198 g
(without clamp and cable)
