Sennheiser e614 - Specifications

7
Specifications
Transducer principlepre-polarised
condenser microphone
Frequency response 40....20,000 Hz
Pick-up pattern super-cardioid
Sensitivity
(free field, no load at 1 kHz) 3 mV/Pa
Max. sound pressure level
at 1 kHz 139 dB/SPL
Nominal impedance 50 Ω
Min. terminating impedance 1 kΩ
Phantom powering 12 – 52 V / 3 mA
Connector XLR-3
Dimensions Ø 20 mm, L 100 mm
Weight 93 g
