Replacing the headband Replacing the ear pads
Cleaning
1 Peel off the large headband padding.
Wearing with small headbandsWearing with large headband padding
1 Remove both small headbands.
2 Collapse the split headband.
3 Mount the large headband padding. 2 Mount the small headbands.
Specifications
Transducer principle
Type
Directivity
Transmission rate
Sensitivity
Impedance
Max. sound pressure level
Interface
Power supply
Microphone
BMD 434
pre-polarized condenser
microphone
dynamic
cardioid super-cardioid
40 – 20,000 Hz 40 – 18,000 Hz
16 mV/Pa @ 1 kHz 0.5 mV/Pa @ 1 kHz
– 300 Ω
–
–
–
Phantom-powered P12–P48
12 V – 48 V
BKE 10-4
150 dB SPL, 1 kHz, 0.5% THD
Ambient temperature
Weight without cable
General Data
Storage: -55 °C to +70 °C
approx. 240 g
Operation: -15 °C to +55 °C
Transducer principle
Ear coupling
Frequency response
Impedance
Power rating
Sensitivity
Max. sound pressure level
Limiter off
Max. sound pressure level
Limiter on
Ambient noise reduction
Distortion
Power supply /
consumption
Contact pressure
Headphone
dynamic, closed
circumaural
8 Hz – 18,000 Hz
64 Ω
500 mW
128 dB SPL @ 1 kHz
110 dB SPL @ 1 kHz 110 dB SPL @ 1 kHz
ANR on/off
–
600 Ω ANR on /
200 Ω ANR off
112 dB SPL / 1 V
rms
/ 1 kHz Limiter off 112 dB SPL / 1 V
rms
/ 1 kHz
ANR on, Limiter off
107 dB SPL / 1 V
rms
/ 1 kHz
ANR off, Limiter on/off
115 dB SPL @ 1 kHz ANR on
128 dB SPL @ 1 kHz ANR off
≤ 32 dB passive ANR off respectively
additonal ≤ 15 dB ANR on
< 0.1% @ 1 kHz, 100 dB SPL
approx. 3.3 N
– Phantom powered P12-P48
12 V – 48 V, ≤ 10 mA
HME 27 HMD 27 HMDC 27
2 Pull the headband carrefully apart.
